Model:
ADMT-6B
-
Features:
The DC resistivity & IP instrument is a reliable, cost-effective tool for groundwater exploration, offering mature technology and proven performance, delivering significant economic benefits to well-drilling units and individuals.
High precision：The latest circuit design, single-chip control, automatic noise reduction, and digital filtering to greatly improve the measurement accuracy and stability；
Simple operation：Humanized man-machine interface, built-in formula calculation of various devices, direct reading VP, IP, SP, RO, M, TH and other related parameters；
Many parameters：VP, IP, SP, RO, M, TH and other related parameters can be measured；
Complete equipment：Ten types of equipment including four-pole sounding, intermediate gradient, joint profile, five-pole, and three poles.
R&D Since 1973
Stable Accurate
6-Month Trade-Up Guarantee
The ADMT-6B Multi-Function DC Resistivity & IP Meter revolutionizes traditional electrical exploration equipment by offering a compact, lightweight design. It features intelligent analysis software, user-friendly operation, and exceptional convenience.
Light &
Portable
Accurate
& Stable
Fully
Equipped
Simple
Operation
PRINCIPLE & FEATURES
The ADMT-6B uses DC resistivity and induced polarization methods to detect groundwater. By supplying DC current to the ground and analyzing received data, it calculates parameters like apparent resistivity, polarization rate, half-decay time, deviation, and comprehensive IP to identify groundwater. As a fundamental geophysical water-finding instrument, it features mature technology, reliable performance, and delivers significant economic benefits to well-drilling units and individuals, recognized as a cost-effective and dependable electrical method for water exploration.
VERSATILE APPLICATIONS
Groundwater Exploration
Iron Mineral Exploration
Environmental Census
Engineering Investigation
Detailed surveys and general exploration of groundwater
Survey and exploration of various metallic and non-metallic minerals
It is widely used in environmental protection survey, electric power design, engineering prospecting, geothermal prospecting, coal mine goaf, geological disaster survey, etc.
SEVEN ADVANTAGES
TO HELP YOU EXPLORE WORRY-FREE
High precision
Features advanced circuit design, microcontroller control, automatic noise reduction, and digital filtering. Significantly improves measurement accuracy and stability
Simple operation
User-friendly interface, built-in formulas for various devices
to directly read VP, IP, SP, RO, M, TH
and other related parameters
Rich parameters
Capable of measuring a wide range of geophysical parameters including VP, IP, SP, RO, M, and TH
Fully equipped
Ten device types including quadrupole sounding, intermediate gradient, joint profile, five poles, and three poles
Safe and reliable
Overvoltage, overcurrent and battery protection, power display and data protection against power down
Stable performance
High-performance circuit shooting. Self-electric compensation and anti-interference ability have reached an excellent state. Field measurements are fairly stable
Lifetime technical support
Lifelong support for data processing, instrument maintenance, and online technical assistance
BEAUTIFUL IN SHAPE
① Power connector ② Power supply AB terminals ③ MN Measurement terminals ④ LCD screen ⑤ Brightness adjustment ⑥ Swtich ⑦ Keyboard ⑧ USB interface
TECHNICAL PARAMETERS
| Parameter | ADMT-6B |
|---|---|
| Voltage measurement range | 2500mV～＋2500mV |
| Voltage resolution | 0.001mv |
| Input impedance | ≥50MΩ |
| Apparent susceptibility measurement accuracy | ±1% ±1digit |
| SP compensation range | ±2500mV |
| Current channel | 6A, ±4% ±1digit |
| Current resolution | 0.02uA |
| Suppress 50Hz power frequency interference | Better than 80dB |
| Max. transmit power | 6000W |
| Upper limit of supply voltage | 1000V |
| Upper limit of supply current | 6A |
| Power supply waveform | Pulse width 1-60 seconds, duty ratio 1:1, bipolar |
| RAM | 2GB (support 32GB expansion) |
| Power supply | 14.8V 5200mAH lithium battery |
| Working environment | -10℃～+50℃，95%Rh |
| Storage temperature | -20℃～+60℃ |
| Main unit weight | 4.2kg |
Trusted by Millions, CCTV Recommended
SERVING THE WORLD
PROFESSIONAL SERVICE TEAM
QUALIFICATION CERTIFICATE
Certificates and Awards: CE, ISO, China National High-tech Enterprise, China National Technical Invention Patent
R&D Since 1973
1973: Developed the domestic short-wire D75 electrical method
1977: Developed an aerial proton
magnetometer
1981: Developed domestic resistivity DW83 electrical method
1988: Developed a
multi-functional high-power electric method
2001: Developed the NEP series of natural electric field
geophysical probes
2005: Completed the "High-Density Electrical Method" project commissioned
by the Institute of Geology and Geophysics, Chinese Academy of Sciences
2011: Completed the
"Controllable Source Geodetic Electromagnetic Instrument (CSAMT)" project commissioned by the
Institute of Geology and Geophysics, Chinese Academy of Sciences
2013: Received the support of the
Innovation Fund of the Ministry of Science and Technology, and passed the Shanghai High-tech Achievement
Transformation Certification
2017: Developed mobile phone water-finding instrument and geophysical
instrument, supporting two-dimensional and three-dimensional automatic mapping of Android system
2018:
Independent research and development of 16-channel series products to solve the problem of natural electric
field source changes, simple, efficient and precise
2021: Water-finding instrument, geophysical
prospecting instrument, aerial geophysical prospecting, earthquake advanced prediction system, etc. will be
developed for cloud platform big data automatic analysis function
2022: The company was renamed
Shanghai Aidu Intelligent Detection Technology Co. Ltd, and expanded its business operations
2023:
Launched AI automatic analysis functionality, ushering geological exploration into a new era of
intelligence. Introduced speedy water exploration instruments, magnetotelluric instruments, and
high-precision three-component magnetometers
2024: Released an online monitoring system supporting ERT,
bipole electrical, magnetic, and other geophysical data acquisition, with integrated data fusion and
processing capabilities for geological hazard monitoring and prevention
2025: Released UAV magnetic
survey and unmanned boat electrical survey systems with automated acquisition, rapid imaging, cloud-based
inversion processing capabilities
